Compact Power: with Double Telescopic (DT) technology, the DT Truck 50 offers a wide working area and impressive versatility. Compact yet powerful, it’s crane-certified and ideal for municipalities and private businesses alike.

Compact Versatility

DT Truck 50

The DT Truck 50 features our exclusive Double Telescopic (DT) technology, offering an expansive and nearly semicircular working area. This means you can reach more points and work more efficiently at height.
This aerial working platform is remarkably compact and can be fitted on commercial trucks with a minimum Gross Vehicle Weight (GVW) of 6173 lbs. Despite its small size, it can accommodate a basket up to 5’9″, boasting a generous payload capacity of 507lbs.
Like all our machines, the DT Truck 50 is crane-certified, allowing for hook and winch attachments. This flexibility extends its usability across various applications, making it a top choice for both municipalities and private businesses.

Minimun GVW: 6173lbs.

Max. working height: 50ft

Negative work: -6ft 7in

Up and over clearance: 26ft 3in

Horizontal outreach: 73ft

Platform height: 15m

Basket capacity: 507lbs

Stabilization: H+H

Hook capacity: 573lbs

Turret rotation: 720°

Basket dimensions: 4’7″X2’4″X3’7″

Basket rotation: 90° + 90°

Platform controls: ELECTRONIC
