Cela Fire ALP505

Aerial ladder platforms ALP505

The ALP505’s self-leveling turntable ensures a stable platform, even on challenging terrain, setting it apart from conventional firefighting equipment.
With an extended telescopic jib and a lengthy reach, the ALP505 provides unparalleled access to hard-to-reach areas.
High Load Capacity: Boasting a generous 520 kg load capacity in the basket, it accommodates firefighting equipment and personnel with ease.
The expanded basket dimensions of 2.2 x 1 x 2 meters offer ample space for equipment storage and efficient operation.
Negative Work Capability: The ALP505 excels in negative work scenarios, allowing it to operate below ground level, making it a versatile asset in complex firefighting and rescue missions.

Applications:
– Challenging terrain and complex firefighting scenarios.
– Extended reach and access to elevated or below-ground locations.

The ALP505 is the epitome of versatility and innovation in firefighting equipment. Trust it to conquer the toughest challenges with ease.

Minimum GVW: 26T

Max. working height: 50m

Negative work: -13m

Up and over clearance: 32m

Horizontal outreach: 30m

Lift capacity: 520kg

Water capacity: 3800l/min

Operating wind speed: 14m/s

Rescue cage size: 2000x1200x1100mm

Foldable front platform: 1360×520mm

Cela Fire ALP505 technical data
Cela Aerial ladder platforms ALP505 technical data
Cela Aerial ladder platforms ALP505 technical data
Cela Aerial ladder platforms ALP505 technical data
